DVB-T221 Car DVB-T2 DVB-T MULTI PLP Digital TV Receiver automobile DTV box, Sony EW300, DVB-T2 Mplp, DVB-T2 Multi PLP

Car dvb-t2 TV tuner diversity digital receiver set top box + Antenna, support multi PLP
DVB-T221 Car DVB-T2 tv receiver USB HDTV 2 Antenna Japan Tuners High Speed

DVB-T221 Car DVB-T2 tv receiver USB HDTV 2 Antenna Japan Tuners High Speed

1. Now Support DVB-T / DVB-T2 + High Speed.
(Now DVB-T, future updated DVB-T2, once buy, save money.)
2. Support Multi PLP, say goodbye to missing channel
3. Support H.264/AVC, MPEG2~MPEG4 HD Video Decode;
4. Available to upgrade the firmware via USB slot;
5. USB Recorder, PVR, multimedia play, support HDD;
6. Auto searching and updating bit rate information;
7. Storage for 2000pcs channels;
8. Memory function after power off;
9. Support OSD TELETEXT;
10. Multi Language Support: English, Russian,Thai, Spanish etc.
11. EPG program guide and PIG(Picture in Graphics )Function;
12. 6MHz, 7MHz, 8MHz Band-wide;
13. HD output (One route);
14. 2x Video output, Stereo Audio-R, Audio-L output;
15. Support IR output and extended remote sensor receiver;
16. Google DVB-T221 to get perfect technology support and update software.
17. Support AUX AV input.
19. 10~32V widely power supply, special designed for car or bus.
20. Smart module design, even built-in your dvd / gps play.
21. Touch screen operation is optional. (Need debug and ODM)
22. Power DC jack, one cigarette lighter to connect easily
1. Does DVB-T221 support DVB-T1 and DVB-T2 received both (simulcast)?
VCAN: Yes, DVB-T221 support DVB-T1 and DVB-T2 both.

2. Does DVB-T221 support H.265 (HEVC)?
VCAN: It supports H.264 decoder, but not H.265(HEVC).

3. Does DVB-T221 support CI+?
VCAN:  It not Support CI, please check this model: DVB-T3000CI support.
Car dvb-t2 TV tuner diversity digital receiver set top box + Antenna, support multi PLP
1. Input frequency: VHF 177.5MHz - 226.5MHz UHF 474MHz - 858MHz
2. Modulate: QPSK/16 - QAM/256-QAM
3. Decode standard: MPEG4,MP@ML,MP@HL,H.264/AVC
4. Audio decode standard: MPEG-1, and-2,layer and 2, MPEG-4, HE-AAC
5. Two ways CVBS RCA + One HD output:
6. Power Supply: DC 12V~26V 5W
7. Connecting Terminal:
Active amplifier antenna input jack (3.3V supply), Car power input jack , R/L Audio CVBS Video output jack,
External remote control IR cord, USB upgrade socket, HD High-definition output jack.
8. Applicable Power Supply: Car storage battery (12V~ 24V)
9. Outer dimension: 125mm x 85mm x 26mm
10. Application Temperature: -5 ~40 degree
11. Storage Temperature: -20~60 degree

Technology Data:
TV Standard Fully SD/HD Tuner DVB-T/T2,  SD/HD MPEG2 and  MPEG4 AVC H.264
Video Resolution Full HD tuner DVB-T2,support up to 1080P
Video System Automatic PAL/NTSC conversion
Video Ratio Aspect ratio 16:9 and 4:3
Channels Number 1000 channels memory
OSD Language OSD language: English, Thailand, Russia, Spainish more please visit
EPG Small windows screen picture with EPG graphic menu,7-Day EPG function
Channel Search Auto search & Manual search function
Software upgrade Software upgrade via USB
Teletext Support teletext/ subtitle/audio language selection,VBI Teletext,Teletext/ Bit Map subtitle
Save Channel Automatic save for last channel
LCN Support Logic Channel Number(LCN)
1.Main Chip Sets
Flash Memory 32MB Serial Flash
DDR2 Memory 512MB
Input Frequency VHF:  174~230MHz,UHF: 470~862MHz
RF input Level -20~-83dBm
RF Bandwidth 6MHz-7MHZ and 8MHZ
Modulation QPSK,16QAM,64QAM,256QAM
3.USB Decode
DVR supporting Stereo/MONO/Left/Right
Media Supporting USB2.0 Port, playback the media in USB flash disk or USB HDD
USB2.0 HOST DVR with USB HDD, Time shifting with USB HDD
music MP3,WMA
5.Video Decode
Decode Format
MPEG-2 MP@HL, MPEG-4 SP, DIVX1 3.11(Optional), 4.X, 6.X,FLV Format,

 H.264MP@HL, VC-1,RM&RMVB(Optional)
 Output Format  1080p,1080i,720p,576p,576i,480p,480i
Aspect Ratio 4:3/16:9/Letterbox/ selectable
Output Port CVBS and HD Out
6.Audio Decode
Decode Format MPEG-1,MPEG-2 (Layer I/II),MP3, AC-3(Optional),E-AC-3(Optional),AAC-LC,HE-AAC 5.1
Audio output RCAX2(L/R) + HD Out (Audio)
7.AV Output
Video Bandwidth 5.5MHz(-3dB)
Video Impedance 75Ω
Video Voltage Level 1.0 Vp-p
Audio Freq. Range 20~20KHz
Guard internal 1/4,19/128,1/8,19/256,1/16,1/32,1/128
Pilot pattern PP1-PP7
Power Supply DC(10V-26V)
Hardware interface DC input 12V, 2 Antenna input, USB, HD out, AUX AV in, CVBS AV out, IR sensor, Power Indicator
Audio format ISO/IEC14496-30,AAC,AAC+
FFT 1K,2K,4K,8K,16K,32K
Power 2 W
Video resolution 576i,576p,720p,1080i and 1080p
Audio Impedance 600Ω
Audio Voltage Level 2V rms(5.6Vp-p)

1 X Car DVB-T2 receiver
2 X 25DB car amplifier digital DVB-T2 Antenna
1 X power / ir / av cable
1 X Remote Control Unit
1 X Extended IR Cable
1 X Audio Video output cable
1 X Users' manual

Unit Outer dimension:
14cm x 8.5cm x 2.6cm

Paking details:

Product Name:
Size per carton: 64*45*26(cm)
Single weight: 1.1 (kgs)
Quantity per carton: 20 (pcs)
Weight per carton: 22(kgs)
Single size:
